Demo Commander Series 3000 Gallon Tanker Contact for Pricing
Call to inquire 315 000-0000
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
TANK:
New 3000-gallon Polypropylene ELLITPCIAL tank and body
• Tank to come with a lifetime warranty.
Standard Features:
• ¾” and ½” Polypropylene construction
• Primed and painted finish to match the chassis
• Electronic water level gauge
• 6” Internal Vent
• Scene light and beacon light brackets
• Polypropylene conduit for wires
• Mild steel skid (Hot Dip Galvanized)
• All tanks are spring mounted to chassis in the front and middle and solid mounted in rear
TANK OPENINGS:
(1) 4” opening in rear street side of tank – Valve and male NST fitting on rear of tank – 2.5”
– Bray butterfly valves with stainless steel flanges
(1) 4” box sump located front bottom center to supply pump with 4” Air operated valve
DUMP VALVE(S):
(1) 10” Newton dump valve on rear – Stainless steel
(1) Newton SWIVEL attachment on rear dump valve
(1) Slide-out extension on rear swivel
APPARATUS BODY ACCESSORIES:
Two (2) Aluminum diamond tread catwalks, one each side
Two (2) Aluminum diamond tread storage compartments
– Aluminum swing-open doors on each compartment
– 60” x 26” x 26” Compartment on driver side
– 60” x 26” x 26” Compartment on passenger side
– LED interior compartment lights
– Sweep-out floors
One (1) Aluminum hose tray on driver side and passenger side catwalk
One (1) Electric swing down porta-tank rack on passenger side
- Built to fit 3500 gallon “Fol-da-tank”
- Aluminum diamond tread cover or matching painted cove
WATER PUMP SYSTEM:
Berkeley B3ZRMS PTO driven centrifugal pump
750 GPM Max Discharge
65 PSI Max Pressure
• 1 – 2.5” discharge on driver side between cab and tank with valve and 2.5” fitting
• 1 – 2.5” discharge on passenger side between cab and tank with valve and 2.5” fitting
• 1 – 1.5” Pre-connect discharge on driver side catwalk – 150’ Capacity
(1) 2” Pump recirculation
(1) Class 1 Twister throttle and ENFO IV display
(1) 1.5” Aquatrol relief valve to drain to the ground – Set at 130 PSI
– All stainless-steel plumbing and manifolds
Electronic Water Level Gauges:
(1) Class 1 ITL-40 Electronic water level gauge on pump panel
(1) Whelen PSTANK Electronic water level gauge on rear of tank
CHASSIS:
2026 International HV607tandem axle
Color: RED
Motor: Cummins L9 450 Hp.
Transmission: Allison Automatic EVS transmission
Aluminum wheels on front axle
Aluminum wheels on rear axle
315/65R x 22.5 Tires on front axles
11R22.5 tires on rear axles
18,000# front axle capacity
46,000# rear axle capacity
5.29 rear axle ratio
Hendrickson Haulmaxx spring suspension
Inter-axle differential lock
Air conditioning
AM/FM Radio
Tow hooks front and rear
Master battery disconnect switch in cab
Air horns underneath cab to leave room for any light bar
EMERGENCY LIGHTING:
One (1) Whelen Justice Series LED light bar mounted on cab roof
Two (2) Whelen L31HF Series Super-LED beacons on top rear of tank
o Located on top rear corners of tank
Eight (8) Whelen M7 Series Super-LED light heads in lower zones
o Two (2) located in front grille
o Two (2) located near front fenders
o Two (2) located near rear fenders
o Two (2) located on rear lower zone of truck
Three (3) Whelen M9EZ Series LED scene lights
– One (1) located on left side of tank
– One (1) located on right side of tank
– One (1) located on rear head of tank (Rear lights to come on when truck is in REVERSE)
Six (6) LED Ground lights
o Two (2) located under cab steps
o Two (2) located under storage compartment
o Two (2) located under rear corners of tank
Whelen 100-watt speaker
Whelen 295SLSA1 Siren amplifier
Sealed beam LED Stop/Turn/Tail lights on rear of tank
Custom aluminum center console
MISCELLANEOUS ITEMS:
4” Reflective stripping on each side of apparatus
Chevron striping on lower rear section of tanker
Rear vision camera system
– Infrared rear camera for night vision
– 7” LCD screen in cab
– Audio for sound in cab
